NSI SC-2/0 Short Copper Compression Splice, 2/0 AWG Online Sale

Original price was: $6.48.Current price is: $2.59.

SKU: US-8302997864664 Categories: , Tags: , , , , , , , , , , , , , , , , ,

Description

NSI SC-2/0 Short Copper Compression Splice, 2/0 AWG

NSI SC-2/0 Short Copper Compression Splice, 2/0 AWG

  • Produced from high conductivity copper tubing
  • Serrations indicate proper crimp locations
  • Tin-plated to provide corrosion resistance
  • Marked with die index and color coded
  • Suitable for use at voltages up to 35kV provided connector is properly installed to cable manufacturer voltage stress relief instructions, 5KV is the maximum voltage in all bare splices

Product Drawing



Specifications

Voltage: 600V
Material: Copper
Finish: Tin Plated
Ul Standard: UL 486A
Barrel Inside Diameter: 0.44
Barrel Outside Diameter: 0.56
Wire Cable Class: Class B, Class C
Conductor Type:
 Copper
Temp Rating: 90C, 9CU
Wire Range: 2/0 AWG
Die Color Coded: Black
Barrel Length: 1.75
