Description

Resilient Sounds RS NEO 8 400w RMS 4ohm 8″ speaker

Neo 8



800 Watts Max Power Handling



2″ Voice Coil



98 dB Sensitivity



100HZ-8.5KHz of frequency response



GENERAL SPECIFICATIONS



Nominal Diameter          8″ (203mm)

Max Power Handling      800 w

RMS Power Handling     400 w

Frequency Response      100Hz-8.5KHZ

Nominal Impedance       4ohm

Sensitivity                         98dB

Magnet                              Neodymium

Voice Coil Diameter        2″

Voice Coil Wire               CCAW



THIELE-SMALL PARAMETERS



Equivalent Volume         Vas        9.53 L

Free Air Resonance        Fs           99 Hz

Mechanical Factor          Qms      4.18

Electrical Factor Qes       0.31

Total Factor       Qts        0.29

Cone Area          Sd          216.4cm²

Mechanical Mass            Mms     17.83 g

BI Factor                           BI           10.68 Tm

Dc Resistance                  Re          3.2 Ohms



MOUNTING INFO



Overall Diameter                          8.26”(210mm)

Front Mount Baffle Cutout          7.32″(186mm)

Mounting Depth                           3.11″(79mm)

Overall Depth                                 3.51″(89.3mm)
