Description

SounDigital EVO X Remote Level Control Bass Knob

Remote level control for monoblock EVOX amplifiers.

COMPATIBLE WITH THE PRODUCTS:

• – 800.1 EVOX2
• – 1000.1 EVOX2
• – 1600.1 EVOX2
  – 3000.1 EVOX2
• – 5000.1 EVOX2
• – 8000.1 EVOX2
• – 12000.1 EVOX
• – 20000.1 EVOX
• – 35000.1 EVOX

• TECHNICAL SPECIFICATIONS

  Can be used for 12V, 24V or HV systems
  Overvoltage protection
  4 wires (1 used only in case of HV system)
  Input: 5 V – 30 V
  Range (Low Voltage): 5 V- 30 V
  Range (High Voltage): 50V – 440 V
  Precision (Low Voltage) : +-0,1 V
  Precision (High Voltage) : +- 1V
  Current Draw (Max): 30mA
  Dimensions (H X W X L): 4.5 x 8 x 2 cm
